Shell Material:
| W1 | Stainless Steel Housing:AISI304/DIN1.4301 | Steel Clip (Optional):AISI304/DIN1.4301 | Bolt:AISI12L14/DIN1.0737(Dacromet Coating) | Axis Pin:AISI12L14/DIN1.0737 (Dacromet Coating) |
| W2 | Stainless Steel Housing:AISI304/DIN1.4301 | Steel Clip (Optional):AISI304/DIN1.4301 | Bolt:AISI304/DIN1.4301(Wear-resistant Coating) | Axis Pin:AISI304/DIN1.4301 |
| W3 | Stainless Steel Housing:AISI316L/DIN1.4435 | Steel Clip (Optional):AISI316L/DIN1.4435 | Bolt:AISI316L/DIN1.4435(Wear-resistant Coating) | Axis Pin:AISI316L/DIN1.4435 |
Rubber Seal Material:
| EPDM | Applicable Temperature:-30℃--130C | Applicable media: various water qualities, air, powders and various chemical substances. |
| NBR | Applicable Temperature: -25℃--100C | Applicable Media: gas, oil, fuel and various hydrocarbons. |
| MVQ | Applicable Temperature: -10℃--200℃ | Applicable Media: high temperature liquid, oxygen ozone, water, etc. |
| VITON A | Applicable Temperature: -30℃--260C | Applicable Media: ozone, oxygen, acidic natural gas, petroleum fuel, etc. |
